How to Read a Sectional Chart

The sectional chart is the most important piece of paper in your flight bag. Once you can read it fluently, cross-country navigation opens up. Here's every symbol, color, and marking explained.

How to Read a Sectional Chart

A VFR sectional aeronautical chart is published by the FAA at a scale of 1:500,000 (roughly 1 inch = 6.86 nautical miles). Each chart covers approximately 340 × 340 miles and is updated every 56 days. The chart contains more information per square inch than almost any other document in aviation — airports, airspace, terrain, obstructions, navigation aids, special use areas, and more.

Learning to read a sectional is not difficult, but it takes time in the air with the chart in hand. This guide covers every major symbol category. After reading it, pull up a sectional chart for your local area (free at SkyVector.com or the FAA's VFR chart portal) and identify each type.

Chart basics — what you're looking at

Sectional charts are oriented with true north up. The coordinate grid shows latitude and longitude. The key to interpreting everything on the chart is the chart legend, printed on the reverse side or folded into the margins. Every symbol on the chart is explained there — if you see something unfamiliar, check the legend before guessing.

The chart uses color systematically: blue for controlled airspace and certain airports, magenta for other airspace types and non-towered airports with approaches, brown for terrain (contour lines), green for lower terrain/vegetation, and white for higher terrain. Water is blue.

Airport symbols — the most important marks on the chart

Every airport on the sectional has a symbol with associated data. Understanding airport symbols tells you whether you need a radio, whether there's a control tower, and what services are available.

Airport circle color

Airport circle fill

Airport data block

Next to every airport symbol is a data block. Reading from top to bottom, it typically shows:

  1. Airport name (abbreviated if necessary)
  2. Elevation in feet MSL
  3. CT frequency (control tower frequency, if applicable)
  4. ATIS/ASOS frequency (preceded by "A" for ATIS or "A*" for ASOS)
  5. Runway length — longest runway in hundreds of feet (e.g., "70" = 7,000 ft)
  6. Lighting — an asterisk (*) next to the elevation means pilot-controlled lighting is available
  7. UNICOM frequency — for non-towered airports, usually 122.8 or 123.0 MHz
ℹ️

Traffic pattern altitude: The standard traffic pattern altitude is 1,000 ft AGL, but exceptions are noted in the Chart Supplement (formerly Airport/Facility Directory). Always check the Chart Supplement for your destination airport before flying — pattern altitudes, noise abatement procedures, and local notes are there.

Airspace depictions

Class B airspace

Solid blue circles of varying diameters represent the concentric rings of Class B airspace. Each ring has a label showing the altitude floors and ceilings, e.g. "30/SFC" means from the surface to 3,000 ft MSL in that ring. The innermost ring typically extends from the surface upward.

Class C airspace

Solid magenta circles in two rings (5 nm and 10 nm radius) represent Class C. The inner ring typically goes from the surface, the outer ring from about 1,200 ft AGL. Altitude labels appear on the chart.

Class D airspace

Dashed blue circles surround towered airports. Class D typically extends to 2,500 ft AGL. The ceiling altitude is shown in a box near the airport, e.g. "[25]" means 2,500 ft MSL is the ceiling.

Class E — the confusing one

Class E is shown in three ways on sectional charts:

Special use airspace

Restricted areas appear as blue hatched outlines labeled "R-####". MOAs appear as magenta hatched outlines labeled by name. Warning areas appear as blue hatched outlines with "W-####". Alert areas are light blue with "A-####". Each has an associated altitude range and time of use — check the legend and NOTAMs for current status.

Terrain and obstacles

Contour lines

Brown contour lines show terrain elevation. Each line represents a specific elevation — the interval is printed on the chart (typically 500 ft in most areas, 1,000 ft in mountainous areas). The closer the lines are together, the steeper the terrain. Green color indicates lower elevations; brown/tan indicates higher elevations.

Maximum elevation figures (MEF)

Each quadrant on the chart (bounded by latitude and longitude lines) contains a large blue number — the Maximum Elevation Figure. This represents the highest terrain or man-made obstacle in that quadrant, rounded up to the next 100 feet and then adding 100 feet. Flying at or above this altitude gives 100 ft of clearance over any obstacle in that quadrant. This is a critical navigation planning tool.

Obstacle symbols

Wind turbine farms are depicted with a specific propeller symbol and have proliferated significantly in the Midwest and plains states. They represent genuine hazards and require careful terrain awareness.

Navigation aids (NAVAIDs)

VOR

VORs appear as compass rose symbols (a hexagon surrounded by a compass rose) in blue or magenta. The name, frequency, and Morse code identifier appear next to the symbol. The compass rose shows magnetic variation-corrected bearings from the VOR. Radials are measured from the VOR outward (magnetic), so a VOR compass rose allows you to immediately visualize which radial you're on from your position on the chart.

NDB

Non-directional beacons appear as a magenta circle with a dot in the center, with name and frequency. Less common than VORs but still on many charts.

ILS/LOC approaches

Feather symbols extending from runways indicate ILS (instrument landing system) or localizer approaches. The feather points in the direction of the approach. Relevant for situational awareness about where IFR aircraft will be descending — stay clear of these paths near airports in IMC.

Using the chart in flight

The practical skill is matching what you see on the chart to what you see out the window — pilotage. As you fly, identify large lakes, rivers, highways, railroads, cities, and prominent terrain features and verify they match the chart. Build a habit of checking your position against the chart every 10–15 minutes on a cross-country, not just relying on GPS.

When planning, measure distances with a plotter. Course lines are drawn with a plotter aligned to the nearest meridian (line of longitude) to get true course, then converted to magnetic heading using the variation shown on isogonic lines (dashed magenta lines labeled with their variation, e.g., "5°W").

💡

Free digital sectionals: Practice chart reading at SkyVector.com — free, always current, and allows zoom. Identify airport data blocks, airspace boundaries, MEFs, and obstacles in your area before your next flight.

Chart currency

Sectional charts are updated every 56 days. Using an out-of-date chart is illegal for navigation (FAR 91.103 requires that a pilot be familiar with all available information — an outdated chart may not reflect new obstacles, airspace changes, or NOTAMs). Free digital charts through ForeFlight, Garmin Pilot, or SkyVector are always current. If using paper charts, check the edition date on the chart cover.
